T-SIM / T-A Standard Series

Model Comparison

Click here [GitHub] to see a comparison of more models.

Product Module QWIIC Seamless
power switching		 GNSS
routing to SOC		 GNSS
PPS		 eSIM
Pad		 BMS Camera
Interface		 DeepSleep
Current		 Pin
compatible
T-A7670X ESP32-WROVER-B(N4R8) ❌ ❌ ❌ ❌ ❌ ✅ ❌ Avg: 157µA ❌
T-A7608X ESP32-WROVER-B(N4R8) ❌ ❌ ❌ ❌ ✅ ✅ ❌ Avg: 240µA ❌
T-SIM7000G ESP32-WROVER-B(N4R8) ❌ ❌ ❌ ❌ ✅ ✅ ❌ Avg: 500µA ❌
T-SIM7600G ESP32-WROVER-B(N4R8) ❌ ❌ ❌ ❌ ✅ ✅ ❌ Avg: 200µA ❌
T-SIM7080G-S3 ESP32-S3-WROOM-1(N16R8) ❌ ❌ ❌ ❌ ❌ ❌ ✅ Avg: 1.1mA ❌
T-SIM7670G-S3 ESP32-S3-WROOM-1(N16R8) ❌ ❌ ❌ ❌ ❌ ✅ ❌ Avg: 497µA ❌
T-A7608X-S3 ESP32-S3-WROOM-1(N16R8) ❌ ❌ ❌ ❌ ❌ ✅ ❌ Avg: 368µA ❌
T-A7670X-S3-Standard ESP32-S3-WROOM-1(NR16R2) ✅ ✅ ✅ ✅ ✅ ✅ ✅ Avg: 314µA ✅
T-SIM7670G-S3-Standard ESP32-S3-WROOM-1(NR16R2) ✅ ✅ ✅ ✅ ✅ ✅ ✅ Avg: 147µA ✅
T-SIM7000G-S3-Standard ESP32-S3-WROOM-1(NR16R2) ✅ ✅ ✅ ❌ ✅ ✅ ✅ Avg: 166µA ✅
T-SIM7080G-S3-Standard ESP32-S3-WROOM-1(NR16R2) ✅ ✅ ✅ ❌ ✅ ✅ ✅ Avg: 128µA ✅
T-SIM7600G-S3-Standard ESP32-S3-WROOM-1(NR16R2) ✅ ✅ ❌ ❌ ✅ ✅ ✅ Avg: 128µA ✅

Tech Support

ℹ️Product Information
Check out our GitHub repository for sample code and more detailed information about this board.

💻Technical support
Visit our GitHub community, post a description of the problem and our engineers will help you directly.
